Yanzeo YZ868 Desktop 20 lines Omni-directional Platform 1D Laser wired Barcode scanner
Optical Resolution:
300*300
Scan Speed:
100 scans/second
Scan Element Type:
CMOS
Interface Type:
USB
Type:
Barcode Scanner
Colour Depth:
32 Bit
Model Number:
YZ868
Product Type:
Bar Code Scanner
Novelty:
New
Time to market:
Aug-04
Scanning Light Source:
Laser Light
Brand Name:
Yanzeo
Scan Breadth:
4-20CM
For the products on the picture below, please click on the image to arrive
Product:
Yanzeo YZ868 Desktop 20 lines Omni-directional Laser Platform 1D Barcode scanner
Place of Origin: Guangdong China (Mainland)
Brand Name: YANZEO
Model Number:YZ868
Name: 1D Barcode Scanner
l Suit for all POS systems and machine.
l Blue and Red LED indicator,double buzzer.
l Plug and play, not need any driver, easy to operate.
l Anti-Scraping protection glass large window design.
l The appearance is novel, fashionable and founder.
l Supports auto-sleep and quickly wake-up functions.
l 20 scan lines with 5 directions at rate of 1650 scans per second.
l Compatibility WindowsXP, Windows7,Windows8,Windows10,ISO etc.
Mainly used in large supermarkets, shopping malls,speciality stores(pharmacy, clothing stores, tobacco, hotels)
OPERATIONAL PARAMETER
Light Source 650nm visible laser diode (VLD)
Depth of Field(DOF): 4mil:10-50mm,5mil:0-90mm, 7.5mil:0-170mm,10mil:0-220mm,13mil:0-240mm
,20mil:0-300mm Note: DOF May vary depending on environment condition and barcode quality
Scan Lines: 20
Scan Rate: 1650 times per second
Minimum Resolution 0.1mm(4mil)@ Code39, PCS=90%
Print Contrast: More than 30% @ UPC/EAN 100%
Visual Indicator: Two color LED （Blue ,Red）
Host System Interfaces HID USB, USB Virtual Com, Rs-232
Beeper Operation Programmable tone & Volume
PHYSICAL CHARACTERISTICS
Dimension H x W x L: 150mm*75mm*150 mm
Weight 490g (without cable), lightweight to save shipping cost.
Material ABS + PC
Cable Standard 1.8M straight
POWER PARAMETER
Input Voltage 5VDCplusmn10%
Working corrent 220mA
SAFETY REGULATORY
Laser Class CE EN55022 B, FCC Part 15 Class B, VCCI, BSM I
EMC CDRH Class IIa, IEC 60825-1 Class 1
ENVIRONMENTAL PARAMETER
Operating Temperature 0degC to 50degC
Storage Temperature -20degC to 60degC
Working Humidity 5% to95% relative humidity, non-condensing
Light Levels 0~4,000Lux（Fluorescence），0~100,000Lux（sunlight）
Drop Durability Designed to withstand 1M drops
DECODE CAPABILITY
UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded
Warranty & Return:
Warranty time：12 Months
we will test before sent the goods.
All products have been checked and packed in good condition before shipped out.
Your order will be shipped within 2 working day of receiving payment (Monday-Friday) and you should expect to receive it 1 to 5 days after shipment, depending on your location.
In the very unlikely event that your item is lost or damaged during shipment, we will either issue a full refund or replacement.
About us
YANZEO is a company specializing in R&D and sales of barcode scanners, data collectors and RFID. It is a high-tech enterprise. We provide high quality, high efficiency and low price services to our major distributors all over the world. Our products are sold. To the United States, Canada, Russia, the United Kingdom, Germany, Brazil, Chile, Australia and South Korea, Thailand and other countries.
Need more please contact us. Will provide the best price and quality.
We are manufacturers and look for agents in various countries around the world. OEM orders and global cooperation are available.
Have any questions,Let us know！
Unit Type:
piece
Package Weight:
0.7kg (1.54lb.)
Package Size:
20cm x 10cm x 10cm (7.87in x 3.94in x 3.94in)
