Honeywell YOUJIE YJ5900 1D Laser Laser Desktop USB Omnidirectional Wired Handfree Automatic Barcode Scanner for POS solutions
Optical Resolution:
300*600
Scan Speed:
100 scans/second
Interface Type:
USB
Type:
Barcode Scanner
Scan Breadth:
A4
Model Number:
5900
Product Type:
Bar Code Scanner
Scanning Light Source:
Laser Light
Brand Name:
Honeywell
Scan Element Type:
1D
Optimal solution 5900 is a high performance, compact design, omni-directional multi linear laser barcode scanner, a convenience store and all kinds of store choice for.
In the default state, 5900 per second can produce 1650 intensive laser line, bar code scanning time pass rate is high, can greatly enhance the work efficiency and customer satisfaction.
5900 of the flexible and convenient installation, set aside 4 fixing screw holes, with convenient fixed at retail counters or production line on the desktop, for the user to effectively save valuable space.
The 5900 product is the optimal solution of 5800 on the basis of upgrading, stable performance, low failure rate, can be operated continuously for a long time. In addition, the 5900 configuration better buzzer, louder sound can ensure that users in a noisy environment is still able to timely and accurate feedback message heard reading.
Including other patent technology: IR infrared self sensing mode, the user can replace the cable and Flash ROM software upgrade.
Physical parameters
Size (length x width x height): 87mm x 98 mm x 170 mm
Weight: 170 g
Electrical parameters
Input voltage: 5 VDC ± 0.5 V
Power: 1.4W (275mA, 5V) - the typical value
Standby power: 1.2W (230mA, 5V) - the typical value
DC power: Class2; 5.2VDC@1A
Laser safety: Class2: IEC60825-1
Product certification: CE, EN55022 Class A; IEC 60950-1, IEC62471
Environmental parameters
Working temperature: -20 ° C - 40 ° C
Storage temperature: -40 ° C - 60 ° C
Humidity: 5%-95% relative humidity, non condensed state
Illumination: 4842LUX (450 foot candles)
Shock resistance: can withstand the 1 m air fall
Performance parameters
Source: visible laser diode laser, the wavelength of 650 nm ± 10 nm
Buzzer: 7 tones or silent
Indicator: Green = laser light, ready to scan; red = decoding success
System interface: USB, RS232 serial port
Scanning patterns: omnidirectional multi line: 5 directions, each direction of the 4 scanning lines
Scanning speed: omni directional multi line: 1650 times / sec
Print contrast can be identified: Reflection minimum 35% difference
Angle, elevation angle, angle: 360 °, 60 °, 60 °
Decoding ability: all standard barcode
Unit Type:
piece
Package Weight:
0.3kg (0.66lb.)
Package Size:
15cm x 10cm x 5cm (5.91in x 3.94in x 1.97in)
